MAXXTURN 65

The perfect solution for economic, off-the-shelf complete machining. With its comprehensive equipment the MAXXTURN series has everything the customer needs in order to produce complex turned and milled parts efficiently – in terms of precision as well as of price.

MAXXTURN 65

EQUIPMENT

  • Main and counter spindle Tool
  • Y axis directly implemented in the machine construction
  • 12-position tool turret with milling drive
  • EMCO bar and gantry loader
  • emcoNNECT – Digital Process Assistant (option)
  • Optional BMT turret for powerful milling and drilling operations
  • Siemens Sinumerik One or Fanuc 31i B

TECHNICAL DATA

WORK AREA

Travel in X/Y/Z 260 / +/-50 / 610 mm
Bar diameter 65 (77/95) mm
Max. turning diameter 500 mm
Swing over bed 725 mm
Spindle distance Main Spindle – Counter Spindle: 840 mm
Rapid motion speeds in X/Y/Z 30 / 15 / 30 m/min

MAIN SPINDLE

Max. speed 5000 (4500/3500) rpm
Spindle nose A2-6 (A2-8/A2-8)
Max. drive power 29 (29/37) kW
Max. torque 250 (250/360) Nm

COUNTER SPINDLE

Max. speed 7000 rpm
Spindle nose A2-6
Max. drive power 22 kW
Max. torque 130 Nm

TOOL TURRET

VDI size 30 (40) / BMT45P / BMT55P
Number of tools 12 / 16
Driven tools 12 / 16
Max. speed 5000 (4500) / 12000 rpm
Max. drive power 6.7 / 8 / 10 kW
Max. torque 25 / 20 / 30 Nm

GENERAL DATA

Dimensions (LxWxH) 3500 x 2350 x 2150 mm (withour chip conveyor)
Machine weight 7000 kg

HIGHLIGHTS

  • High thermostability and precise machining High rapid motion speed
  • Radial turret with single-motor engineering
  • Very stable Y axis with long travel High-precision C axis
  • Very compact machine layout
  • Driven tools 12 time VDI30 (VDI 40)
  • State-of-the-art control technology from Siemens of Fanuc for simple dialog-supported programming
