Software Accessories Software

OPC UA umati Interface WinNC

The OPC UA umati Interface for WinNC is an umati-compatible OPC UA server that connects EMCO machines to external systems through a network. It allows machine data to be read and monitored using a standardised interface.

The interface can also send commands to the machine and write control-specific parameters. This supports machine monitoring, program management and the integration of EMCO Concept machines into connected manufacturing environments.

opc ua umati interface winnc featured

Monitoring Functions

  • Current tool
  • Active program
  • Current parameters
  • Safety gate status
  • Clamping device status
  • Axis positions
  • System status, including errors, warnings and reference status
  • Operating mode, including automatic and manual modes
  • Current program line

Control Functions

  • Change tools
  • Load programs by program name
  • Start programs
  • Write control-specific parameters
  • Open and close the safety door
  • Open and close clamping devices
  • Start a reference run

Licences

Machine licence

  • Interface software for all EMCO Concept machines

Applications

  • Machine data monitoring
  • Network connection to external systems
  • Connected manufacturing environments
  • Machine status reporting
  • Tool and program monitoring
  • Program loading and starting
  • Control parameter management
  • Error and warning monitoring
  • Machine command control

Interface Specifications

  • Interface type: Umati-compatible OPC UA server
  • Network communication: OPC UA
  • Machine compatibility: EMCO Concept machines
  • Data access: Machine data reading and control commands
  • Specification: OPC 40501-1 Machine Tools – Monitoring and Job Overview
  • Server profile: MachineTool Basic Server Profile

Supported Server Facets

  • MachineTool Monitoring Server Facet
  • MachineTool Tools Server Facet
  • MachineTool Errors and Alerts Server Facet

PDF Downloads

X5A_051_010_OPC_UA_umati_WinNC_DE-EN_A
