ALL-PURPOSE TURNING MACHINE FOR PRECISE AND HIGH-PERFORMANCE MACHINING
With the new UNIVERSALTURN 50, EMCO sets the next milestone in complete machining of bars and chuck parts. Developed
for maximum precision, dynamics and process reliability, the
compact high-performance turning centre offers everything
that modern manufacturing centres require: powerful drive
systems, an integrated Y-axis for extended milling and flexible
automation concepts.
Whether complex turned and milled parts for mechanical en
gineering, the automotive industry, medical technology or de
fence – the UNIVERSALTURN 50 impresses with its outstanding
rigidity, intuitive operation and scalable equipment.
Thanks to proven EMCO technologies combined with forward
looking developments, users benefit from maximum efficien
cy, high cost-effectiveness and the highest level of manufac
turing quality.
Experience a new dimension in precision and productivity –
made by EMCO.
The tool turret of the UT50 SMY, designed for machining operations with a high proportion of milling, has a BMT45P interface with 12 positions and integrates dual motor technology: one servo motor drives the swivel movement and another water-cooled motor, integrated in the turret disc, drives the tool holders directly
The integrated spindle motors (ISM) of the UNIVERSALTURN 50, mounted in large precision bearings, offer a wide speed range and excellent concentricity – ideal for economical machining of steel and high-speed cutting of aluminium. Symmetrically designed spindle stocks, temperature sensors at the bearing points and liquid cooling ensure high thermal stability and process reliability.
The counter spindle is mounted on a separate roller guide and moves automatically over 510 mm. A stroke-monitored, coolant-flushed parts ejector ensures reliable removal of the workpieces. A hollow clamping cylinder with 50 mm passage is available as an option – ideal for unloading long shafts through the counter spindle.
The UNIVERSALTURN 50 is currently available exclusively with the modern SINUMERIK ONE control system from Siemens. This offers an intuitive, dialogue-based programming system and seamless integration into digital manufacturing processes
Continuous-path control with high sophisticated technology functions using digital drives for standard and complex machining, such as turning, milling, drilling, rigid tapping, polygon turning, High dynamical and precise digital drives.
Bar Loader options available - Details on request.
With main spindle, tailstock and turret including milling drive. Designed for machining medium-sized chuck, shaft, or bar parts. It impresses with its user-friendly handling, high accuracy, fast changeover processes, and efficient cost-effectiveness
Work Area
