Manual Machines

MANUAL MACHINES

High precision lathes with and without cycle control. Universal milling machines with and without cycle control

EMCOMAT

High precision lathes with and without cycle control

EMCOMAT E-200 MC

  • Distance between centres  1000 mm
  • Max turning dia  400mm
  • Spindle bore  Ø 50/53 mm
  • Max. speed  4000 rpm
  • Drive performance  7.5 / 10kW

EMCOMAT-14 D

  • Distance above centres  140 mm
  • Distance between centres  650 mm
  • Spindle bore  Ø 40 mm
  • Max. speed  4000 rpm
  • Max. drive performance  7.5 kW

EMCOMAT-17 D

  • Distance above centres  170 mm
  • Distance between centres  700 mm
  • Spindle bore  Ø 50 mm
  • Max. speed (17S)  2350 rpm
  • Max. speed (17D)  3000 rpm
  • Max. drive performance (17S)  3.2 kW
  • Max. drive performance (17D)  5.3 kW

EMCOMAT-20 D

  • Distance above centres  200 mm
  • Distance between centres  1000 mm
  • Spindle bore  Ø 50 mm
  • Max. speed  3000 rpm
  • Max. drive performance  5.3 kW

EMCOMAT FB-SERIES

Universal milling machines with and without cycle control

EMCOMAT FB-3

EMCOMAT FB-3

  • Clamping area  600 x 200 mm
  • Max. table load  50 kg
  • Max. speed  2200 rpm
  • Drive power milling spindle  1.4 kW
EMCOMAT FB-450 MC

EMCOMAT FB-450 MC

  • Clamping area  800 x 400 mm
  • Max. table load  300 kg
  • Max. speed  5000 rpm
  • Power milling spindle  10 kW
EMCOMAT FB-600 MC

EMCOMAT FB-600 MC

  • Clamping area  800 x 400 mm
  • Max. table load  300 kg
  • Max. speed  5000 rpm
  • Power milling spindle  13 kW
