Emco MaxxTurn 200

MAXXTURN 200

  • Main and counter spindle (optional) for turning and milling operations
  • One or two tool turrets for flexible turning, drilling and milling operations
  • Swing over bed up to 1000 mm
  • Max. workpiece weight 6 t
  • State-of-the-art dialog-supported Siemens control
  • emcoNNECT – Digital Process Assistent (840D sl)
Emco MaxxTurn 200

MAXXTURN 200

  • Solid machine design for heavy-duty cutting
  • Counter spindle and 2nd turret for maximum productivity
  • Maximum machining accuracy
  • Stable Y-axis with long carriage travel (+/- 125 mm)
  • Driven tools including C-axis
  • emcoNNECT – Digital Process-Assistent (Siemens 840D sl)

Work area

  • Travel in X/Y/Z: 550 / +/-125 / 2050-4050-6050 mm
  • Max. turning diameter: 1000 mm
  • Swing over bed: 1050 mm
  • Distance between centers: 2200 / 4200 / 6200 mm
  • Rapid motion speeds in X/Y/Z: 15/30/30 m/min

Main spindle

  • Max. speed: 1800 rpm
  • Spindle nose: A2-15”
  • Max. drive power: 84 kW
  • Max. torque: 6410 Nm

Counter Spindle

  • Max. speed: 2000 / 2500 rpm
  • Spindle nose: A2-15” / A2-11”
  • Max. drive power: 53 kW
  • Max. torque: 4400 Nm

Tailstock

  • Automatic tailstock: yes
  • Quill diameter: 200 mm
  • Inner cone: MK6
  • Quill travel: 250 mm

Tool turret

  • VDI size: 60 /BMT85
  • Number of tools: 12
  • Driven tools: 12
  • Max. speed: 3000 rpm
  • Max. drive power: 19,8 kW
  • Max. torque: 116 Nm

General data

  • Dimensions (LxWxH): BL 2200-8600x3450x3360//BL 4200/6200- 11100/13400x3450x3360 mm
  • Machine weight: BL 2200/4200/6200: 30/40/50 t
Product Description

MAXXTURN 200

  • Solid machine design for heavy-duty cutting
  • Counter spindle and 2nd turret for maximum productivity
  • Maximum machining accuracy
  • Stable Y-axis with long carriage travel (+/- 125 mm)
  • Driven tools including C-axis
  • emcoNNECT – Digital Process-Assistent (Siemens 840D sl)
Technical Data

Work area

  • Travel in X/Y/Z: 550 / +/-125 / 2050-4050-6050 mm
  • Max. turning diameter: 1000 mm
  • Swing over bed: 1050 mm
  • Distance between centers: 2200 / 4200 / 6200 mm
  • Rapid motion speeds in X/Y/Z: 15/30/30 m/min

Main spindle

  • Max. speed: 1800 rpm
  • Spindle nose: A2-15”
  • Max. drive power: 84 kW
  • Max. torque: 6410 Nm

Counter Spindle

  • Max. speed: 2000 / 2500 rpm
  • Spindle nose: A2-15” / A2-11”
  • Max. drive power: 53 kW
  • Max. torque: 4400 Nm

Tailstock

  • Automatic tailstock: yes
  • Quill diameter: 200 mm
  • Inner cone: MK6
  • Quill travel: 250 mm

Tool turret

  • VDI size: 60 /BMT85
  • Number of tools: 12
  • Driven tools: 12
  • Max. speed: 3000 rpm
  • Max. drive power: 19,8 kW
  • Max. torque: 116 Nm

General data

  • Dimensions (LxWxH): BL 2200-8600x3450x3360//BL 4200/6200- 11100/13400x3450x3360 mm
  • Machine weight: BL 2200/4200/6200: 30/40/50 t
