• Dimensions (W x D x H) in mm – 747 x 851 x 821
• Repetition accuracy – ± 0,02 mm
• Travel ranges in mm – 320 x 230 x 72
• Distance focus – Depending on focusing lens
• Laser type – Ytterbium fibre laser
• Laser power (max.) in W – 200 (optional 400)

• Speed range – 100 mm/s
• Connection voltage – 16 A 110/-240 V
• Focal distance in mm – 100, 125 or 200
• Laser cooling – Air-cooled
• Modulation frequency in kHz – up to 500
• Wavelength in nm – 1070

• Weight in kg – approx. 146
• Marking/cutting speed in m/min – 6
• Typical materials – Paper and card, Plastics, Thin metal sheets, Wood and veneer
• Application examples – Cutting foils and veneers, Cutting thin plastic panels, Marking ceramic surfaces, Marking glass surfaces, Marking steel, Surface marking

POWERFUL

• 200 Watt or 400 Watt laser

CONSTRUCTION

• Machine with complete protective laser enclosure

LINE THICKNESS

• Line thicknesses of up to 0.05 mm

CONNECTION

• Connection to a conventional PC via USB cable

TECHNOLOGY

• Low-maintenance, modern laser diode technology

MOTORS

• servo motors
