• Dimensions (W x D x H) in mm – 510 x 775 x 660
• Repetition accuracy – /
• Travel ranges in mm – Z: 235
• Distance focus – /
• Laser type – Ytterbium fibre laser

• Laser power (max.) in W – 10 to 100
• Speed range – /
• Connection voltage – 230 V / 16 A
• Laser cooling – Air-cooled
• Wavelength in nm – 1070

• Weight in kg – approx. 40
• Marking/cutting speed in m/min – 480
• Typical materials – Ceramic, Leather, Metals, Plastics, Wood, paper, card
• Application examples – Surface engraving

SIZE

• Clamping area of 400 x 400 mm
• Working area of up to 200 x 200 mm

AXIS

• Electrically adjustable Z-axes

CONSTRUCTION

• Machine with complete protective laser enclosure
• No rework necessary

CONNECTION

• Connection to a conventional PC via USB cable

SPEED

• Marking speed of up to 8 m/s with galvo scanner head

INCLUSIVE!

• Suction unit
• Including marking software
